Description
Number of Pages: 16
This is a reproduction, not a photocopy, of an original Hardinge Super-Precision Horizontal Milling Machines model TM and model UM parts manual. This manual covers the original models in the 1950s that are below serial number 32273 . The serial number is stamped on the front of the table. We have the parts manual for newer Hardinge milling machine models with higher serial numbers at the following link:
HARDINGE Milling Machine Models TM & UM Parts Manual Serial #32273 & Up
This manual contains cross sectional view diagrams of all the parts of these horizontal Hardinge milling machines. We’ve also included the sales flier for this mill that contains information about the machine specifications and the attachments and accessories. We also have the owner’s manual for these Hardinge mills as well in at the following link:
HARDINGE Horizontal Milling Machine Owner’s Operator & Maintenance Manual
Overview:
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
