Description
Number of Pages: 136
This is a reproduction, not a photocopy, of an original 1956 Cincinnati Dial Type Horizontal & Vertical Milling Machines Operator’s Instruction Manual. This manual covers the following models: 210-12, 310-12, 315-15, 415-15, 420-16, and 520-16.
This manual contains the mill dimensions and installation instructions for both the plain and universal models. The manual covers all the proper operating procedures. It covers all the various handles and shows how to setup the automatic table feed cycles. The mill manual includes lubrication and maintenance instructions. It shows how to make various adjustments. For example, it shows how to adjust the spindle bearings, the backlash eliminator, and the traverse clutch.
The manual coves a lot of different accessories like the dividing head, curricular milling table, vertical milling attachment, high speed universal milling attachment etc… It also shows how to install and basic operating instructions.
Overview
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench. Better than a pdf download.
