Description
Number of Pages: 33, printed 5.5″ x 8.5″
This is a reproduction, not a photocopy, of an original Craftsman Bench Saw and Jointer Handbook. This is a complete handbook covering all the branches of table saw and jointer operation in the home workshop with over 100 hundred photographic illustrations and line drawings. This book goes into more detail on operations and set ups than the owner manuals do. It even includes information on how to adjust the tables properly. The information in this book is good for a variety of different vintages and brands of table saws and jointers. Please see index below.
One reason that I’ve reprinted some of these older books is because they have a lot of information with illustrations that get directly to the point.
Contents:
THE BENCH SAW
BEVELS……………………..7,15
COMPOUND MITERS…………….16,32
COVES…………………………8
CROSSCUTTING…………………..6
CUT-OFF JIG…………………..10
CUT-OFF WHEELS………………..12
DADO OPERATIONS…………….13,14
DOVETAIL GROOVING……………..19
FILING VISE…………………..20
GAINS………………………..14
JOINTING VENEER………………..9
METAL CUTTING…………………12
MITERS……………………..7,15
MITER BOARD…………………..10
PATTERN SAWING…………………9
RABBETING…………………..7,14
RESAWING………………………6
ROLLER SUPPORT…………………5
SANDING………………………12
SPLINE GROOVES………………7,14
STANDARD OPERATIONS…………..5-7
SHARPENING SAWS…………….20,21
TAPER RIPPING…………………11
TENONING JIG………………….10
TENONS…………………….13,18
TENON SIZES…………………..32
WOOD JOINTS………………..15-19
THE JOINTER
BEVELS……………………….26
CHAMFERS …………………….29
EDGE JOINTING…………………25
END JOINTING …………………26
PLANING THIN WORK……………..25
PUSH BLOCKS…………………..25
RABBETING…………………….28
RECESSING…………………….29
SETTING JOINTER KNIVES…………31
SHARPENING JOINTER KNIVES………30
STOPPED TAPERS………………..28
SURFACING…………………….24
TAPER JOINTING………………..26
TENONS……………………….28
Overview:
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
