Description
Number of Pages: 19
This is a reproduction, not a photocopy, of an original American Tool Works Co. Radial Drills with 13″, 15″, 17″ & 19″ Columns with 32-Speeds Owner’s, Operator’s, Instructions Manual. This manual contains operating instructions, adjustments, and maintenance. This American Tool Works manual also contains information on the tapping attachment, adjusting the spindle and spindle sleeve, fix oil leakage at spindle nose, and making adjustments to the elevating clutch and replacing the elevating nut.
We have the parts manual for a similar American Tool Works Co. Radial Drill here:
AMERICAN Tool Works Hole Wizard Deluxe 32 Speed Radial Drill Part Manual
Overview
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench. Better than a pdf download.
