Description
Number of Pages: 33 + 3 foldouts
This is a reproduction, not a photocopy, of an original TOS BPH20 Surface Grinder approximately 10″x25″ Operator’s and Parts Manual. This manual contains information on operating instructions, maintenance, adjustments, lubricating instructions and a complete set of cross sectional diagrams of the parts for this TOS Surface Grinder. Please see index below.
PDF Download is Available
The manual has the option for either a PDF Download or a quality Printed copy with card stock covers and a comb binding. After purchase an email will be sent with link to download the PDF. The PDF will not be password protected, but your contact information will be watermarked at the bottom of the pages.
Index
I. General Data……………………………………………..5
Acceptance chart……………………………………………..5
Notes on removals…………………………………………….5
Standard equipment……………………………………………6
Optional equipment……………………………………………6
II. Specification…………………………………………….6
Dimensions and weights………………………………………..6
Capacity…………………………………………………….6
III. Technical description…………………………………….6
IV. Transport of machine……………………………………..7
Acceptance of machine…………………………………………7
Transport and slinging………………………………………..7
V. Erection of machine……………………………………….7
Choice of site……………………………………………….7
Foundation…………………………………………………..7
Levelling of machine………………………………………….7
VI. Electrical equipment and switch gear
Connection to the mains……………………………………….8
Specification of electrical equipment…………………………..8
Description of electrical equipment…………………………….8
Protection against accidents…………………………………..8
Maintenance of electrical equipment…………………………….8
Connection to the mains……………………………………….9
VII. Description of main machine groups……………………….10
Hydraulic system…………………………………………….10
Relief valve………………………………………………..11
Cross slide…………………………………………………11
Bed………………………………………………………..11
Grinding spindle…………………………………………….11
Grinding wheel flanges……………………………………….12
Dressing attachment………………………………………….12
Cooling equipment……………………………………………12
Exhausting attachment………………………………………..12
VIM. Operation and putting the machine into operation…………..12
List of control elements……………………………………..12
Lubrication…………………………………………………13
Starting and trial run……………………………………….13
Clamping of workpiece……………………………………….13
Proper grinding……………………………………………..13
Face grinding……………………………………………….13
IX. Causes of possible defects and their remedy………………..13
X. Economic grinding……………………………………….14
Diagram of time required for grinding………………………….15
XI. Review of difficulties in grinding and their remedy…………15
XII. List of standardized and built-in stocked parts…………… 17
Bearings……………………………………………………17
Belts………………………………………………………17
Seals………………………………………………………17
XIII. List of parts subject to wear……………………………18
Table with sketches of spare parts…………………………….18
XIV. Lubrication of machine………………………………….18
Lubrication chart – lubricants used……………………………19
XV. Instructions how to order spare parts……………………..20
Supplement………………………………………………….20
Review of figures and table
Operation of machine………………………………………….1
Slinging of machine…………………………………………..2
Foundation plan………………………………………………3
Hydraulic system……………………………………………..4
Relief valve…………………………………………………5
Sketch of reversed cross slide…………………………………6
Shifter……………………………………………………..7
Grinding spindle……………………………………………..8
Clamping of grinding wheel…………………………………….9
Cooling equipment……………………………………………10
Exhausting attachment………………………………………..11
Lubrication…………………………………………………12
Wiring diagram………………………………………………13
Diagram of time required for grinding………………………….14
Overview:
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
