Description
Number of Pages: 20
This is a reproduction of an original Kearney Trecker Milwaukee SI-61 Milling Machine Installation Manual with S-12 knee types.
Contents:
|
Uncrating………………………………………………………………. |
9 |
|
Shortages……………………………………………………………… |
9 |
|
Hoisting………………………………………………………………… |
9 |
|
Cleaning……………………………………………………………….. |
10 |
|
Location……………………………………………………………….. |
10 |
|
Leveling the Machine………………………………………………. |
10 |
|
Table Assembly……………………………………………………… |
11 |
|
Table Bracket Left Hand………………………………………….. |
12 |
|
Thrust Bearing Adjustment……………………………………….. |
12 |
|
Table Bracket Right Hand………………………………………… |
13 |
|
Thrust Bearing Adjustment Check……………………………… |
13 |
|
Electrical Connections……………………………………………… |
14 |
|
Pulley Belt Adjustment…………………………………………….. |
14 |
|
Gib Adjustments…………………………………………………….. |
14 |
|
Lubrication Instructions |
|
|
Plain and Universal………………………………………………….. |
15 |
|
Vertical and Ram……………………………………………………. |
16 |
|
Machine Dimensions |
|
|
Plain, Universal and Vertical……………………………………… |
17 |
|
Ram Head…………………………………………………………….. |
18 |
|
Plan Dimensions……………………………………………………… |
19 |
Overview:
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
