HARDINGE Automatic Threading Unit on HC Chucking Machine Maintenance Manual

Id: 0938

$25.00

100 in stock




Description

Number of Pages: 19

This is a reproduction, not a photocopy, of an original Hardinge Automatic Threading Unit on Model HC Chucking Machine Maintenance Manual. This manual contains information set up, lubrication, installation on machines, and instructions on how to replace and adjust nearly every part on this unit. Please read contents below.



We also have the operator’s manual for this unit in our store as well.





Contents:

Air Connections…………………………………..3
Chasing Head — Disassembly…………………………8
Reassembly………………………………………12
Cycle Stop Micro Switch — Replacement……………….8
Cylinder Housing, Chasing Head……………………..6
Disassembly………………………………………6
Reassembly……………………………………….6
Electrical Connections…………………………….4
Electric Control Functions…………………………4
Feed Rate Adjusting Screw — Removal…………………6
Replacement………………………………………6
Gib Adjustment, Tool Post Slide……………………12
Installation, Automatic Threading Unit………………3
Knockout Control — Disassembly…………………….14
Reassembly………………………………………18
Lubricant Vendors…………………………………2
Lubrication…………………………………..12,19
Lubro-Control Unit……………………………….19
Maintenance, Preventive……………………………2
Mounting Bracket and Chasing Bar Assembly…………..18
Removal, Automatic Threading Unit…………………..5
Serial Number……………………………………13
Slide Travel Adjusting Screw — Removal………………6
Replacement………………………………………6
Tool Post — Disassembly……………………………5
