Description
Number of Pages: 22
This is a reproduction, not a photocopy, of an original 1977 Fellows Gear Shaper Company Service Repair Book for 7 & 7A type high speed gear shapers. This manual contains sections on determining location of upper worm with worm wheel, aligning upper worm-box, adjusting upper worm and worm wheel for correct backlash, aligning lower worm-box, adjusting lower worm and worm wheel for correct backlash, aligning cutter and work spindles, replacing cutter-spindle bushing and test alignment, removing and reassembling cutter-spindle in saddle, removing roller bearing work-spindle from apron quill, and setting and changing cutter angle blocks.
We also have the parts manual for these 7 and 7A Fellows gear shapers in our store.
Overview:
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear, which is better than a low-resolution pdf download.
