VAN NORMAN 22L, 22LU, 22P, 22PU Ram Type Universal Milling Machine Manual

$30.00

100 in stock

Description


Number of Pages: 20

This is a reproduction, not a photocopy, of a Van Norman Models 22L, 22LU, 22P & 22PU Ram Type Universal Milling Machine Instructions and Parts Manual. This manual contains information on set up, lubrication, maintenance, adjustments, and controls as well as a complete parts list and exploded view diagrams. Please read contents below.

Contents:
PRELIMINARY INSTRUCTIONS
Handling………………………………….5
Installation………………………………5
Leveling………………………………….5
Wiring and Electric Controls………………..5
OPERATION
Feed Changes………………………………7
Feed Locks………………………………..6
Hand Feeds………………………………..6
Power Feeds……………………………….5
Power Feed Stops…………………………..6
Power Rapid Traverse……………………….6
Speed Changes……………………………..6
SAFETY DEVICES
Power Safety Stops…………………………6
Safety Clutch……………………………..6
GENERAL INFORMATION
Milling Operations…………………………8
PERIODIC MACHINE ADJUSTMENTS
Gib………………………………………7
Head……………………………………..7
Overarm…………………………………..7
Ram………………………………………7
Rapid Traverse Clutch………………………6
Spindle Bearing……………………………7
Universal Saddle…………………………..7
LUBRICATION
Cutterhead………………………………..8
Feed Drive Chain…………………………..8
General Information………………………..8
Knee Bearing Face………………………….8
Knee……………………………………..8
Miscellaneous……………………………..8
Power Feed Drive…………………………..8
Ram………………………………………8
Table and Saddle…………………………..8
Table Feed Screw…………………………..8
Column Details……………………………10
Head Details……………………………..11
Ram Details and Shifter……………………12
Ram Details………………………………13
Table Details…………………………….14
Saddle Details……………………………15
Universal Saddle Detail……………………16
Front of Knee…………………………….17
Knee – Right Side…………………………18
Knee – Left Side………………………….19
Knee Gearing……………………………..20

Overview
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
