Number of Pages: 15
This is a reproduction, not a photocopy, of an original Cincinnati Instructions for Designing Profiling Templates & Variable Feed Cams for Cincinnati plain and duplex HyPowermatic milling machines with and without tracer control Manual. This manual contains information about designing profiling templates and things to take into consideration and how to properly mount the template. The manual also covers designing cams for variable feed attachments, and provides the formulas and things to take into consideration.
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear. These can be much more useful than a low resolution pdf download.
