AMES A-6000 A-2300 A- 6100 Enclosed Head Bench Metal Lathe Parts Manual

Id: 0014


0 out of 5

100 in stock

Click Here to Pay by Check/Money Order
Print Page


Number of Pages: 7

This is a reproduction, not a photocopy, of an original Ames Enclosed Head Bench Lathe Parts Manual. This manual contains parts diagrams for the A-6000 headstock with 1″ capacity, the A-2300 compound slide rest, and the A-6100 tailstock. There are also a couple of pages on accessories for the headstock and tailstock. The lathe was originally covered in three different manuals. I’ve collected all the different manuals and combined them together here. The manuals are hard to come by in a full set, and there weren’t a lot of these lathes made.






I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
